bottle carton partiton assembly machine | carton package machine

bottle carton partiton assembly machine | carton package machine - Welldoing trading limited

Short Description:

Certification : ISO9001 ,CE

Application : Commodity, Machinery & Hardware, Textile, Alcohol, Toy, Chemical, Apparel, Gifts & Arts, Dining, Medical, Food

After- Sales Service Provided: Overseas Third-Party Support Available

Automatic Grade: Automatic

Send email to us Download as PDF

Product Detail

Product Tags

bottle carton packaging making partition assembly machine

design feature:
* The longitudinal vacuum suction is adsorbed to the paper
* Transverse pneumatic to the paper, accurate and fast
* Vertical longitudinal ically of the paper frame
* The lifting of the transverse feed paper supply workbench adopts electric adjustment
* Electrically adjust the height of the transverse lattice panel
* Cross the paper vertically and horizontally
* Suitable for a variety of box partition, block automatic insertion
* Double plex paper, double efficiency
* The comprehensive use of gas control and electric control ensures the advancement of equipment control
* PLC human-machine interface, easy to operate

Name	Unit	Data
Horizontal inserting width: A	mm	120~900
Lengthways sheets length: B	mm	210~450
Clapboard Height: C	mm	70~300
Horizontal clapboard distance: D	mm	20~400
Lengthways clapboard distance:E	mm	45-800
Lengthways sheets No.	pcs	1-6
Horizontal clapboard No.	pcs	1-21
Carton inserting mouth width:F	mm	＞board thickness
Carton thickness:G	mm	1.5~8mm

certificate:

Our Services

1. OEM service are available.
2. Trade Manager online, also contact by Email.
3. To solve problems by pictures/videos.
4. Engineers are available service abroad.

WELLDOING TRADING Co. Ltd. is a manufacturer + sales and after-sales company, which is mainly engaged in large-scale semi-automatic chain-bar water-based printing machine,automatic flexo printer slotter die cutter stacker machine , high-speed high-definition paper box printing and slotting die-cutting machine, 2 layers corrugated production line, box-sticking machine, Tying Machine ,Automatic Partition Assembler Machine,automatic carton box folder gluer machine, semi-automatic carton floder gluer machine paper tube making machine, flexo ink printing wastewater treatment machine 3,5,7ply corrguated cardboard production line and so on.
