The front-end paper feeding counts automatically, and the paper feeding table is equipped with a light sensor, which rises automatically during paper feeding.The rear electric baffle is driven by stepping motor, with accurate size and convenient and fast transformation.Double servo drive, accurate accuracy, reduced mechanical transmission part, which can effectively reduce the failure rate of machinery.

Semi automatic carton stitching machine characteristics:

1, automatic lifting table (no opto-electronic devices)

2, up button

3, rise photoelectric

4, down button

5, machinery, speed 500 nail/min.

6, bottom die, blade adopt the Japanese tungsten steel production (wear)

7, rubber wheel clearance adjustment: in the panel on the left button, rotating button clockwise rotation is rubber wheel clearance reduce:make the button clockwise rotation is rubber wheel clearance increase, In order to provide direct input in the thickness of the carton, the machine automatically adjust thickness.

8, carton width adjustment: the left and right baffle move to both sides, will board folding put into nailing position were moving around on both sides of the carton board close to leave paper 2 mm gap, then fixed damper.

9, Double piece semi-automatic stitcher machine touch screen operation, the parameters (nail distance, nail number, nail type, tailgate) transformation convenient, quick, PLC control system,7 inch screen.

10, posterior segment with automatic counting function, completes the finished product number of sheets can be directly set number (1-99), batch sent to the conveying machinery end,Convenient packaged banding.

11, the pin head all adopt the special steel production.

12, nail line with automatic alarm device.

13, import double servo drive, precision accurate, mechanical transmission part decreases, can effectively reduce the mechanical failure rate.

14, electric tailgate, adopt the stepping motor drive, precise size, frequency conversion size more convenient and quick. semi automatic corrugated box stitching machine
