Production process of Full Automatic box stitching machine

During the production process of the corrugated cardboard stitiching machine, operators often place a piece of cardboard in the nailing section. Depending on the thickness of the cardboard, workers set the relevant pressure and adjust the width of the support frame of the nailing machine according to the length and thickness of the cardboard? When the thickness of the cardboard is relatively thick, the operator will press the stapling part slightly thinner to prevent the surface paper from being crushed during the stapling process.

At the same time, according to relevant production requirements, nails and nail boxes should be worked along the middle part, with a deviation of no more than three millimeters, and the distance between each nail should be relatively uniform. The distance between the head and tail should not exceed 20 millimeters, the distance between single nails should not exceed 55 millimeters, and the distance between double nails should not exceed 75 millimeters. After the operation is completed, specialized personnel are required to inspect the product. During the verification process, the cardboard box can be placed under natural light to observe whether the nails are firmly and thoroughly nailed, and there should be no nails, warped nails, missing nails, broken nails, removing nails, and no corners. During the operation of the Cardboard stitching machine, the two pieces of cardboard should not have scissors on them, and the cardboard box must be square after folding. For cardboard boxes with a comprehensive size less than 1000mm, the difference between the two diagonals should not be greater than 3mm. However, when the comprehensive deviation of the inner diameter of the tile wheel cardboard box is greater than 2mm, the double wheel cardboard box should not be greater than 4mm. For cardboard boxes with a comprehensive size greater than 1000mm, the difference between the two diagonals should not be greater than 5mm. However, when the inner diameter deviation of my cardboard box cannot exceed 3mm, the online course direction should not be greater than 5mm, and the diameter of the two box corner holes should not be greater than 4mm. At the same time, there should be no obvious corners, and their gap and overlap should not be greater than 2mm. During the use of the box nailing machine, there should be no phenomenon of inverted nails. Two boxes with different specifications and varieties cannot be nailed together.

As is well known, in order to ensure the personal safety of the operators and the normal operation of the Automatic carton nailing machine, it is necessary to ensure that the operators have professional skills during the operation process. Before operation, it is necessary to carefully inspect the motor and the triangular belt of the box nailing machine. You can observe and check whether it is flexible and whether there is any oil leakage. Next, turn on the switch of the nail box machine for operation, press and hold the foot switch, check if there is any abnormal sound, and if there is any abnormality, make sure to repair it. During the operation, the operator holds the front end of the cardboard box with his left hand and pulls it forward, while his right hand supports the other end to help stabilize the movement of his right hand. His left hand is usually fixed and does not make a sound. When encountering some larger boxes, his left hand will also move along and stop at a distance of about 40 centimeters from the position where the punch falls.

Our company also has other packaging machines : carton box partition assembler equipment 、 automatic paper angle board machine 、 automatic air bubble film machine 、 flexo water ink wastewater treatment clear machine 、 automatic carton folding gluing stitching machine、 2 color flexo printing slotting die cutting machine 、automatic nail box machine 、 automatic thin blade machine 、automatic stacking machine 、 Kraft paper slitting and rewinding machine and so on .
